MatchcodeZN063-VDL.6N.V7P6Item number ZV-169028 |  |
|---|---|
| Product group | Axial fan |
| Model | Standard |
| Design | |
| Name | ZAplus |
| Blade series | FN |
| Fan series match code | ZN063-VD_.6N.V7P6 |
| Blade diameter [cm] | 63 |
| Motor technology | AC |
| Rated voltage UN [V] UN [V] | 3~400 +/-10% / 3~460 +/-10% |
| Rated frequency fN [Hz] | 50/60 |
| Input power P1 [kW] | 1,75 |
| Rated current IN [A] | 3,7/2,2 / 4,6/2,9 |
| Rated speed nN [min-1] | 1400/1210 / 1590/1220 / 1640/1330 |
| Current rating increase Δ I [%] | 5/10/10 |
| Controlling starting current IA [A] | |
| Operating capacitor C400V [µF] | |
| Thermal class | THCL 155 |
| Minimum permissible flow medium temperature [°C] | -40 |
| Maximum permissible flow medium temperature [°C] | 70 |
| Electrical connection | Junction box |
| Sound pressure level LpA or LwA [dB(A)] | 82-91 |
| Number of wings | 7 |
| Rotor | Aluminium, non-lacquered |
| Wall ring plate | Plastic |
| Conformity | ErP 2015 |
| Weight [kg] | 30.3 |
| Airflow direction | V |
| Model | L |
| Max. volume flow qv, (where psf = 0 Pa) [m³/h] | 19700 |
| Max. pressure psf [Pa] | 330 |
| Max. volume flow qv [m³/h] (at max. psf [Pa]) | 11500 |
 | |
