• Medium pressure axial fans

    MAXventowlet from ZIEHL-ABEGG

Select your language


Type key axial fans MAXventowlet

0 Results



Blade diameter [cm]
clear Close

   Filter

Fan series match code
DN10A-ZIU.GQ.11.G3Item number
ZV-194425
Motor technology
EC
Rated voltage UN
3~380-480V V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-35 bis 40 °C
Number of wings
3
Protection class
IP55
Motor protection
Ultra-short housing: design U
Fan series match code
DN35V-2DK._Item number
ZV-190027
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis 60 °C
Number of wings
7
Protection class
IP55
Motor protection
Short housing: Design K
Fan series match code
DN45V-2DK._Item number
ZV-190235
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis 60 °C
Number of wings
9
Protection class
IP55
Motor protection
Short housing: Design K
Fan series match code
DN45V-2DK._Item number
ZV-190107
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis 60 °C
Number of wings
9
Protection class
IP55
Motor protection
Short housing: Design K
Fan series match code
DN50V-2DK._Item number
ZV-190023
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis 60 °C
Number of wings
9
Protection class
IP55
Motor protection
Short housing: Design K
Fan series match code
DN50V-2DK._Item number
ZV-190021
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis 60 °C
Number of wings
9
Protection class
IP55
Motor protection
Short housing: Design K
Fan series match code
DN50V-2DK._Item number
ZV-189370
Motor technology
AC
Rated voltage UN
3~460 V
Rated frequency fN
60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis 60 °C
Number of wings
9
Protection class
IP55
Motor protection
Short housing: Design K
Fan series match code
DN56V-2DF._Item number
ZV-193655
Motor technology
AC
Rated voltage UN
3~400 V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis 60 °C
Number of wings
9
Protection class
IP55
Motor protection
Long housing
Fan series match code
DN56V-2DK._Item number
ZV-190022
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis 60 °C
Number of wings
9
Protection class
IP55
Motor protection
Short housing: Design K
Fan series match code
DN56V-2DK._Item number
ZV-190029
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis 40 °C
Number of wings
9
Protection class
IP55
Motor protection
Short housing: Design K
Fan series match code
DN71V-4DK._Item number
ZV-173326
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis 60 °C
Number of wings
9
Protection class
IP55
Motor protection
Short housing: Design K
Fan series match code
DN71V-4DK._Item number
ZV-189977
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis 60 °C
Number of wings
9
Protection class
IP55
Motor protection
Short housing: Design K
Fan series match code
DN71V-4DK._Item number
ZV-181012
Motor technology
AC
Rated voltage UN
3~460 V
Rated frequency fN
60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis 40 °C
Number of wings
9
Protection class
IP55
Motor protection
Short housing: Design K
Fan series match code
DN71V-4DK._Item number
ZV-181013
Motor technology
AC
Rated voltage UN
3~460 V
Rated frequency fN
60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis 40 °C
Number of wings
9
Protection class
IP55
Motor protection
Short housing: Design K
Fan series match code
DN80V-4DK._Item number
ZV-190028
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis 60 °C
Number of wings
9
Protection class
IP55
Motor protection
Short housing: Design K
Fan series match code
DN80V-4DK._Item number
ZV-190025
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis 60 °C
Number of wings
9
Protection class
IP55
Motor protection
Short housing: Design K
Fan series match code
DN90A-ZIU.GQ.14.G3Item number
ZV-192689
Motor technology
EC
Rated voltage UN
3~380-480V V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis 40 °C
Number of wings
3
Protection class
IP55
Motor protection
Ultra-short housing: design U
Fan series match code
DN90V-4DK._Item number
ZV-173350
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis 60 °C
Number of wings
9
Protection class
IP55
Motor protection
Short housing: Design K
Fan series match code
DN90V-4DK._Item number
ZV-190108
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis 60 °C
Number of wings
9
Protection class
IP55
Motor protection
Short housing: Design K
Fan series match code
DN90V-4DK._Item number
ZV-174010
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis 60 °C
Number of wings
9
Protection class
IP55
Motor protection
Short housing: Design K
Fan series match code
DN90V-4DK._Item number
ZV-189106
Motor technology
AC
Rated voltage UN
3~400 / 690 V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis 50 °C
Number of wings
9
Protection class
IP55
Motor protection
Short housing: Design K
Fan series match code
FA065-SD_.4I.V6Item number
ZV-107134
Motor technology
AC
Rated voltage UN
3~400V +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL F
Permissible flow medium temperature
10000 bis -10000 °C
Number of wings
6
Protection class
IP54
Motor protection
S
Fan series match code
FB020-2E_.W8.A5Item number
ZV-170174
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 __ / 60 ... Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 70 °C
Number of wings
5
Protection class
IP54
Motor protection
With wall ring plate by request
Fan series match code
FB025-2E_.WC.A5Item number
ZV-162798
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 75 °C
Number of wings
5
Protection class
IP54
Motor protection
D (contact protection on suction side)
Fan series match code
FB025-2E_.WC.A5Item number
ZV-177573
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 75 °C
Number of wings
5
Protection class
IP54
Motor protection
Q (with contact protection)
Fan series match code
FB025-2E_.WC.A5Item number
ZV-162797
Motor technology
AC
Rated voltage UN
1~230+/-10% V
Rated frequency fN
50 __ / 60 … Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 75 °C
Number of wings

Protection class
IP44
Motor protection
A
Fan series match code
FC031-__Q.2C.A7Item number
ZV-187188 (replaced ZV-161250)
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC031-4DQ.2A.A6Item number
ZV-125086
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
6
Protection class
IP54
Motor protection
Q
Fan series match code
FC031-4EQ.2A.A6Item number
ZV-161250
Motor technology
AC
Rated voltage UN
1~230 V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
6
Protection class
IP54
Motor protection
D (contact protection on suction side) / Q (without contact protection)
Fan series match code
FC035-4D_.2C.A7Item number
ZV-141428
Motor technology
AC
Rated voltage UN
3~230/400 +/-10% / 3~265/460 +/-10% V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC035-4DQ.2C.A7Item number
ZV-125090
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC035-4E_.2C.A7Item number
ZV-130769
Motor technology
AC
Rated voltage UN
1~230 V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FC035-4E_.2C.A7Item number
ZV-130768/without a grate
Motor technology
AC
Rated voltage UN
1~230 V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FC035-4E_.2C.A7Item number
ZV-153932/with a grate
Motor technology
AC
Rated voltage UN
1~230 V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q (contact protection on suction side)
Fan series match code
FC040-4DD.4C.A7Item number
ZV-134017
Motor technology
AC
Rated voltage UN
3~400 V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
D (support arms; with wall ring plate by request)
Fan series match code
FC040-4DQ.2F.A7Item number
ZV-125094
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC040-4E_.4C.A7Item number
ZV-141138
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
F (contact protection on suction side)
Fan series match code
FC040-4E_.4C.A7Item number
ZV-141070
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FC040-4E_.4C.A7Item number
ZV-141073
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
Q (contact protection on suction side)
Fan series match code
FC040-4E_.4C.A7Item number
ZV-141036
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
D
Fan series match code
FC040-4EQ.2F.A7Item number
ZV-164131
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC045-4D_.4C.A7Item number
ZV-130789
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FC045-4D_.4C.A7Item number
ZV-141181/without a grate
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FC045-4D_.4C.A7Item number
ZV-153408
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
D
Fan series match code
FC045-4D_.4C.A7Item number
ZV-161107
Motor technology
AC
Rated voltage UN
3~230/400 +/-10% / 3~265/460 +/-10% V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC045-4DQ.4C.A7Item number
ZV-125158
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC045-4E_.4F.A7Item number
ZV-130773
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FC045-4E_.4F.A7Item number
ZV-141071/without a grate
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FC045-4E_.4F.A7Item number
ZV-141178/with a grate
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q (contact protection on suction side)
Fan series match code
FC045-4E_.4F.A7Item number
ZV-140750
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
D
Fan series match code
FC045-4EQ.4C.A7Item number
ZV-125166
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC050-4D_.4F.A7Item number
ZV-130791
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FC050-4D_.4F.A7Item number
ZV-141182/without a grate
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FC050-4D_.4F.A7Item number
ZV-141184/with a grate
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
Q (contact protection on suction side)
Fan series match code
FC050-4D_.4F.A7Item number
ZV-134018
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
D
Fan series match code
FC050-4E_.4F.A7Item number
ZV-130752
Motor technology
AC
Rated voltage UN
1~230V +/-10% V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC050-4E_.4I.A7Item number
ZV-130775
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FC050-4E_.4I.A7Item number
ZV-141072/without a grate
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FC050-4E_.4I.A7Item number
ZV-141183/with a grate
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
Q (contact protection on suction side)
Fan series match code
FC050-4E_.4I.A7Item number
ZV-140751
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
D
Fan series match code
FC050-4EQ.4F.A7Item number
ZV-134482
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC050-6E_.4C.A7Item number
ZV-179953/without a grate
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FC056-4D_.6F.A7Item number
ZV-183459
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FC056-4D_.6F.A7Item number
ZV-180008/without a grate
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FC056-VDQ.6F.V7Item number
ZV-160094
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC056-VDQ.6K.V7Item number
ZV-126807
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC063-4D_.6K.A7Item number
ZV-141346
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FC063-4D_.6K.A7Item number
ZV-170079/without a grate
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FC063-4D_.6N.V7Item number
ZV-155234
Motor technology
AC
Rated voltage UN
3~230/400 +/-10% / 3~265/460 +/-10% V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC063-4DQ.6K.A7Item number
ZV-125205
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC063-4EQ.6N.A7Item number
ZV-132113
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC063-6EQ.4I.V7Item number
ZV-203712
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC063-VDQ.6K.V7Item number
ZV-123995
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC071-4D_.6N.A7Item number
ZV-177725
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 65 °C
Number of wings
7
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FC071-4D_.6N.A7Item number
ZV-171760/without a grate
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 65 °C
Number of wings
7
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FC071-6D_.6K.A7Item number
ZV-141131
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FC071-6D_.6K.A7Item number
ZV-130796/without a grate
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FC071-6E_.6K.A7Item number
ZV-141945
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FC071-6E_.6K.A7Item number
ZV-130780/without a grate
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FC071-VD_.6N.A7Item number
ZV-132519
Motor technology
AC
Rated voltage UN
3~400V +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 65 °C
Number of wings
7
Protection class
IP54
Motor protection
F
Fan series match code
FC071-VDQ.6N.V7Item number
ZV-132521
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 65 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC080-6D_.6K.A7Item number
ZV-141202
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FC080-6D_.6K.A7Item number
ZV-130798
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FC080-6EQ.6N.V7Item number
ZV-162190
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC080-SD_.6K.V7Item number
ZV-134164
Motor technology
AC
Rated voltage UN
3~400V +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
S
Fan series match code
FC080-SD_.6N.A7Item number
ZV-137636/02
Motor technology
AC
Rated voltage UN
3~400V +/-10% V
Rated frequency fN
60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
L
Fan series match code
FC080-SDQ.6K.V7Item number
ZV-132888
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC080-VDQ.7Q.V4Item number
ZV-152886
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 65 °C
Number of wings
4
Protection class
IP54
Motor protection
Q
Fan series match code
FC091-6D_.7Q.A7Item number
ZV-141348
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FC091-6D_.7Q.A7Item number
ZV-140570/without a grate
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FC091-SD_.7Q.V7Item number
ZV-141089
Motor technology
AC
Rated voltage UN
3~400V +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
I
Fan series match code
FC091-SDQ.7Q.V7Item number
ZV-124407
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC091-SDS.7Q.V7Item number
ZV-107146
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
S
Fan series match code
FC091-SDS.7Q.V7Item number
ZV-176453
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 80 °C
Number of wings
7
Protection class
IP54
Motor protection
S
Fan series match code
FC091-XDQ.7Q.V7Item number
ZV-127362
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC100-6D_.8P.A7Item number
ZV-125014
Motor technology
AC
Rated voltage UN
3~230/400 (Δ/Y) +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC100-8DQ.7Q.A7QItem number
ZV-179440
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FC100-ADS.7Q.V7Item number
ZV-107151
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
S
Fan series match code
FC125-AD_.8S.V7Item number
ZV-131159
Motor technology
AC
Rated voltage UN
3~400V +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 40 °C
Number of wings
7
Protection class
IP54
Motor protection
T
Fan series match code
FC125-MDT.7Q.A7Item number
ZV-140500
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FF050-ZI_.DC.A5P1Item number
ZV-184878
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
5
Protection class
IP55
Motor protection
Wall ring plate
Fan series match code
FF050-ZI_.DC.A5P1Item number
ZV-182779
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
5
Protection class
IP55
Motor protection
Pipe installation
Fan series match code
FF050-ZIT.DC.A5P1Item number
ZV-184653
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-35 bis 60 °C
Number of wings
5
Protection class
IP55
Motor protection
T
Fan series match code
FF056-6D_.4I.A5R2Item number
ZV-171007
Motor technology
AC
Rated voltage UN
3~230/400 (Δ/Y) +/-10% V
Rated frequency fN
50 (data available for 60 Hz) Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 70 °C
Number of wings
5
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FF056-6D_.4I.A5R2Item number
ZV-171009
Motor technology
AC
Rated voltage UN
3~230/400 (Δ/Y) +/-10% V
Rated frequency fN
50 (data available for 60 Hz) Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 70 °C
Number of wings
5
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FF056-6D_.4I.A5R2Item number
ZV-171075
Motor technology
AC
Rated voltage UN
3~230/400 (Δ/Y) +/-10% V
Rated frequency fN
50 (data available for 60 Hz) Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 70 °C
Number of wings
5
Protection class
IP54
Motor protection
Q (contact protection on suction side)
Fan series match code
FF056-6E_4I.A5R2Item number
ZV-170492
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 (data available for 60 Hz) Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 45 °C
Number of wings
5
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FF056-6E_4I.A5R2Item number
ZV-170491
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 (data available for 60 Hz) Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 45 °C
Number of wings
5
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FF056-6E_4I.A5R2Item number
ZV-170505
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 (data available for 60 Hz) Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 45 °C
Number of wings
5
Protection class
IP54
Motor protection
D
Fan series match code
FF056-ZI_.DC.A5P1Item number
ZV-182724
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 50 °C
Number of wings
5
Protection class
IP55
Motor protection
Wall ring plate
Fan series match code
FF056-ZI_.DC.A5P1Item number
ZV-182723
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 50 °C
Number of wings
5
Protection class
IP55
Motor protection
Pipe installation
Fan series match code
FF063-6D_.4I.A5R2Item number
ZV-159958
Motor technology
AC
Rated voltage UN
3~230/400 (Δ/Y) +/-10% V
Rated frequency fN
50 (data available for 60 Hz) Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 40 °C
Number of wings
5
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FF063-6D_.4I.A5R2Item number
ZV-159956
Motor technology
AC
Rated voltage UN
3~230/400 (Δ/Y) +/-10% V
Rated frequency fN
50 (data available for 60 Hz) Hz
Thermal class
THCL 155
Permissible flow medium temperature
-10 bis 40 °C
Number of wings
5
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FF063-6D_.4I.A5R2Item number
ZV-159957
Motor technology
AC
Rated voltage UN
3~230/400 (Δ/Y) +/-10% V
Rated frequency fN
50 (data available for 60 Hz) Hz
Thermal class
THCL 155
Permissible flow medium temperature
-10 bis 40 °C
Number of wings
5
Protection class
IP54
Motor protection
Q (contact protection on suction side)
Fan series match code
FF063-6D_.4I.A5R2Item number
ZV-159955
Motor technology
AC
Rated voltage UN
3~230/400 (Δ/Y) +/-10% V
Rated frequency fN
50 (data available for 60 Hz) Hz
Thermal class
THCL 155
Permissible flow medium temperature
-10 bis 40 °C
Number of wings
5
Protection class
IP54
Motor protection
D
Fan series match code
FF063-6D_.4I.A5R2Item number
ZV-174881
Motor technology
AC
Rated voltage UN
3~230/400 +/-10% / 3~265/460 +/-10% V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 70 °C
Number of wings
5
Protection class
IP54
Motor protection
Q
Fan series match code
FF063-6E_.4I.A5R2Item number
ZV-159968
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 (data available for 60 Hz) Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 40 °C
Number of wings
5
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FF063-6E_.4I.A5R2Item number
ZV-159966
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 (data available for 60 Hz) Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 40 °C
Number of wings
5
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FF063-6E_.4I.A5R2Item number
ZV-159967
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 (data available for 60 Hz) Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 40 °C
Number of wings
5
Protection class
IP54
Motor protection
Q (contact protection on suction side)
Fan series match code
FF063-6E_.4I.A5R2Item number
ZV-159965
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 (data available for 60 Hz) Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 40 °C
Number of wings
5
Protection class
IP54
Motor protection
D
Fan series match code
FF063-6E_.4I.A5R2Item number
ZV-170998
Motor technology
AC
Rated voltage UN
1~230+/-10% V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 70 °C
Number of wings
5
Protection class
IP54
Motor protection
Q
Fan series match code
FF063-ZI_.DG.A5P1Item number
ZV-184648
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
5
Protection class
IP55
Motor protection
Wall ring plate
Fan series match code
FF063-ZI_.DG.A5P1Item number
ZV-184858
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
5
Protection class
IP55
Motor protection
Pipe installation
Fan series match code
FF063-ZI_.DG.A5P1Item number
ZV-184929
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
5
Protection class
IP55
Motor protection
Support arm
Fan series match code
FF071-6D_.6F.A3P2Item number
ZV-169731
Motor technology
AC
Rated voltage UN
3~230/400 +/-10% / 3~265/460 +/-10% V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 70 °C
Number of wings
3
Protection class
IP54
Motor protection
Q
Fan series match code
FF071-6D_.6F.A3P2Item number
ZV-169735
Motor technology
AC
Rated voltage UN
3~230/400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 70 °C
Number of wings
3
Protection class
IP54
Motor protection
T
Fan series match code
FF071-ZI_.DG.A3P1Item number
ZV-184930
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 50 °C
Number of wings
3
Protection class
IP55
Motor protection
Wall ring plate
Fan series match code
FF071-ZI_.DG.A3P1Item number
ZV-184934
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 50 °C
Number of wings
3
Protection class
IP55
Motor protection
Pipe installation, accessories: Stainless steel pipe installation bracket 071 -125, Artikel Nr. ZZ-00283496
Fan series match code
FF080-6D_ 6F A3P2Item number
ZV-169851
Motor technology
AC
Rated voltage UN
3~230/400 +/-10% / 3~265/460 +/-10% V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
3
Protection class
IP54
Motor protection
T
Fan series match code
FF080-6E_.6F.A3P2Item number
ZV-169856
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 55 °C
Number of wings
3
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FF080-ZI_.DG.A3P1Item number
ZV-184935
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
3
Protection class
IP55
Motor protection
Wall ring plate
Fan series match code
FF080-ZI_.DG.A3P1Item number
ZV-184882
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
3
Protection class
IP55
Motor protection
Pipe installation, accessories: Stainless steel pipe installation bracket 071 - 125 Artikel Nrr. ZZ-00283496
Fan series match code
FF091-6D_.6F.A3P2Item number
ZV-159993
Motor technology
AC
Rated voltage UN
3~230/400 (Δ/Y) +/-10% V
Rated frequency fN
50 (data available for 60 Hz) Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 40 °C
Number of wings
3
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FF091-6D_.6F.A3P2Item number
ZV-159991
Motor technology
AC
Rated voltage UN
3~230/400 (Δ/Y) +/-10% V
Rated frequency fN
50 (data available for 60 Hz) Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 40 °C
Number of wings
3
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FF091-6D_.6F.A3P2Item number
ZV-174448
Motor technology
AC
Rated voltage UN
3~230/400 +/-10% / 3~265/460 +/-10% V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 70 °C
Number of wings
3
Protection class
IP54
Motor protection
Q
Fan series match code
FF091-6E_.6F._3P2Item number
ZV-159998
Motor technology
AC
Rated voltage UN
1~230 (Δ/Y) +/-10% V
Rated frequency fN
50 (data available for 60 Hz) Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 40 °C
Number of wings
3
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FF091-6E_.6F._3P2Item number
ZV-159996
Motor technology
AC
Rated voltage UN
1~230 (Δ/Y) +/-10% V
Rated frequency fN
50 (data available for 60 Hz) Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 40 °C
Number of wings
3
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FF091-ZI_.DG.A3P1Item number
ZV-184651
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
3
Protection class
IP55
Motor protection
Wall ring plate
Fan series match code
FF091-ZI_.DG.A3P1Item number
ZV-184879
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
3
Protection class
IP55
Motor protection
Pipe installation, accessories: Stainless steel pipe installation bracket 071 - 125 Artikel Nr. ZZ-00283496
Fan series match code
FN030-4ED.WC.A7Item number
ZV-141631
Motor technology
AC
Rated voltage UN
1~230 V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
With wall ring plate by request
Fan series match code
FN030-4EQ.WA.A7Item number
ZV-153671
Motor technology
AC
Rated voltage UN
1~230 V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FN035-4E_.WD.A7Item number
ZV-162549
Motor technology
AC
Rated voltage UN
1~230 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 60 °C
Number of wings
7
Protection class
IP44
Motor protection
W
Fan series match code
FN035-4E_.WD.V7Item number
ZV-162545
Motor technology
AC
Rated voltage UN
1~230 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 60 °C
Number of wings
7
Protection class
--
Motor protection
K
Fan series match code
FN040-4E_.0F.V7P1Item number
ZV-152728
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 65 °C
Number of wings
7
Protection class
IP54
Motor protection
K (Basket grille)
Fan series match code
FN040-ZI_.DC.A7P5Item number
ZV-184937
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP55
Motor protection
Wall ring plate
Fan series match code
FN040-ZI_.DC.A7P5Item number
ZV-184895
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP55
Motor protection
Pipe installation
Fan series match code
FN045-ZI_.DC.A5P4Item number
ZV-184938
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
5
Protection class
IP55
Motor protection
Wall ring plate
Fan series match code
FN045-ZI_.DC.A5P4Item number
ZV-184896
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
5
Protection class
IP55
Motor protection
Pipe installation
Fan series match code
FN050-4ED.4I.V7P1Item number
ZV-187045
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
D
Fan series match code
FN050-4EQ.4I.V7P1Item number
ZV-167955
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FN050-6E_.4F.V7P3Item number
ZV-167964
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
K
Fan series match code
FN050-VDK.4I.V7P1Item number
ZV-140056
Motor technology
AC
Rated voltage UN
3~400 +/-10% (Δ/Y) V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis -10000 °C
Number of wings
7
Protection class
IP54
Motor protection
K
Fan series match code
FN050-VDQ.4I.A7P1Item number
ZV-140083
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FN050-VDQ.4I.V7P1Item number
ZV-140322
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FN050-ZI_.DC.V7P2Item number
ZV-179667
Motor technology
EC
Rated voltage UN
3~380-400 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-35 bis 60 °C
Number of wings
7
Protection class
IP55
Motor protection
K (Basket grille)
Fan series match code
FN056-4EQ.6N.V7P5Item number
ZV-171043
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FN063-4DQ.6N.V7P6Item number
ZV-167240
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FN063-4EQ.6N.V7P6Item number
ZV-167132
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 55 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FN063-6D_.4I.A7P1Item number
ZV-165418
Motor technology
AC
Rated voltage UN
3~400 +/-10% / 3~460 +/-10% V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
T
Fan series match code
FN063-SD_.4I.A7P1Item number
ZV-141382
Motor technology
AC
Rated voltage UN
3~400V/400V/460V ±10% D/Y V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FN063-SD_.4I.A7P1Item number
ZV-170565
Motor technology
AC
Rated voltage UN
3~400 +/-10% / 3~460 +/-10% V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
W
Fan series match code
FN063-SD_.4I.V7P1Item number
ZV-141384
Motor technology
AC
Rated voltage UN
3~400 +/-10% / 3~460 +/-10% V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
K (Basket grille)
Fan series match code
FN063-VD_.6N.A7P3Item number
ZV-162616
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 65 °C
Number of wings
7
Protection class
IP54
Motor protection
F
Fan series match code
FN065-6E_.6N.V7P1Item number
ZV-169465
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
K
Fan series match code
FN065-SD_.6F.A7P2Item number
ZV-169340
Motor technology
AC
Rated voltage UN
3~400 +/-10% / 3~460 +/-10% V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
W
Fan series match code
FN065-VDP.6N.V7P1Item number
ZV-165618
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
P
Fan series match code
FN071-VD_.6N.A7P2Item number
ZV-179268
Motor technology
AC
Rated voltage UN
3~690 V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
T
Fan series match code
FN080-ADS.6N.V7Item number
ZV-138763
Motor technology
AC
Rated voltage UN
3~400 +/-10% (Δ/Y) V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis -10000 °C
Number of wings
7
Protection class
IP54
Motor protection
S
Fan series match code
FN080-SD_.6N.V7Item number
ZV-138758
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 65 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FN080-SD_.6N.V7Item number
ZV-161244
Motor technology
AC
Rated voltage UN
3~400 +/-10% / 3~460 +/-10% V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
Q
Fan series match code
FN080-SDS.6N.V7Item number
ZV-138757
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 65 °C
Number of wings
7
Protection class
IP54
Motor protection
S
Fan series match code
FN091-6D_.6N.A5P1Item number
ZV-170626
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
5
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FN091-6D_.6N.A5P1Item number
ZV-170153/without a grate
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
5
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FN091-6D_.6N.A5P1Item number
ZV-170029
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
5
Protection class
IP54
Motor protection
T (without contact protection)
Fan series match code
FN091-6D_.6N.A5P1Item number
ZV-169810/without a grate
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
5
Protection class
IP54
Motor protection
Q (without contact protection)
Fan series match code
FN091-SD_.7Q.V5P1Item number
ZV-161365
Motor technology
AC
Rated voltage UN
3~400 +/-10% / 3~460 +/-10% V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 80 °C
Number of wings
5
Protection class
IP54
Motor protection
S
Fan series match code
FN091-SDS.6N.V7P2Item number
ZV-156205
Motor technology
AC
Rated voltage UN
3~400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
S
Fan series match code
FN091-ZI_.GL.A5P1Item number
ZV-184940
Motor technology
EC
Rated voltage UN
1~ 380-480V V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
5
Protection class
IP55
Motor protection
Wall ring plate
Fan series match code
FN091-ZI_.GL.A5P1Item number
ZV-185899
Motor technology
EC
Rated voltage UN
1~ 380-480V V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
5
Protection class
IP55
Motor protection
Pipe installation, accessories: Stainless steel pipe installation bracket 071 - 125 Artikel Nr. ZZ-00283496
Fan series match code
FN091-ZI_.GQ.A5P1Item number
ZV-184644
Motor technology
EC
Rated voltage UN
1~ 380-480V V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
5
Protection class
IP55
Motor protection
Wall ring plate
Fan series match code
FN091-ZI_.GQ.A5P1Item number
ZV-185900
Motor technology
EC
Rated voltage UN
1~ 380-480V V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
5
Protection class
IP55
Motor protection
Pipe installation, accessories: Stainless steel pipe installation bracket 071 - 125 Artikel Nr. ZZ-00283496
Fan series match code
FP045-ZI_.0F.A3P1Item number
ZV-192882
Motor technology
EC
Rated voltage UN
1~200-240V V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-30 bis 60 °C
Number of wings
3
Protection class
IP54
Motor protection
A
Fan series match code
FP045-ZI_.0F.A3P1Item number
ZV-192883
Motor technology
EC
Rated voltage UN
1~200-240V V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-30 bis 60 °C
Number of wings
3
Protection class
IP54
Motor protection
A
Fan series match code
FP045-ZI_.0F.A3P1Item number
ZV-192884
Motor technology
EC
Rated voltage UN
1~200-240V V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-30 bis 60 °C
Number of wings
3
Protection class
IP54
Motor protection
I
Fan series match code
FP045-ZI_.0F.A3P1Item number
ZV-192886
Motor technology
EC
Rated voltage UN
1~200-240V V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-30 bis 60 °C
Number of wings
3
Protection class
IP54
Motor protection
Q
Fan series match code
FP050-ZI_.0F.A3P1Item number
ZV-193906
Motor technology
EC
Rated voltage UN
1~200-240V V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-30 bis 60 °C
Number of wings
3
Protection class
IP54
Motor protection
A
Fan series match code
FP050-ZI_.0F.A3P1Item number
ZV-193907
Motor technology
EC
Rated voltage UN
1~200-240V V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-30 bis 60 °C
Number of wings
3
Protection class
IP54
Motor protection
A
Fan series match code
FP050-ZI_.0F.A3P1Item number
ZV-193908
Motor technology
EC
Rated voltage UN
1~200-240V V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-30 bis 60 °C
Number of wings
3
Protection class
IP54
Motor protection
I
Fan series match code
FP050-ZI_.0F.A3P1Item number
ZV-193910
Motor technology
EC
Rated voltage UN
1~200-240V V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-30 bis 60 °C
Number of wings
3
Protection class
IP54
Motor protection
Q
Fan series match code
FP063-6I_.BD.A3P1Item number
ZV-193873
Motor technology
EC
Rated voltage UN
1~200-277V V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-35 bis 45 °C
Number of wings
3
Protection class
IP54
Motor protection
A
Fan series match code
FP063-6I_.BD.A3P1Item number
ZV-193874
Motor technology
EC
Rated voltage UN
1~200-277V V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-35 bis 45 °C
Number of wings
3
Protection class
IP54
Motor protection
A
Fan series match code
FP063-6I_.BD.A3P1Item number
ZV-193875
Motor technology
EC
Rated voltage UN
1~200-277V V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-35 bis 45 °C
Number of wings
3
Protection class
IP54
Motor protection
S
Fan series match code
FP063-6I_.BD.A3P1Item number
ZV-193877
Motor technology
EC
Rated voltage UN
1~200-277V V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-35 bis 45 °C
Number of wings
3
Protection class
IP54
Motor protection
Q
Fan series match code
QK10A-2DM._Item number
ZV-210991
Motor technology
AC
Rated voltage UN
3~230/400V V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis -10000 °C
Number of wings

Protection class
IP10
Motor protection

Fan series match code
RD31P-4DW._Item number
ZV-133961E
Motor technology
AC
Rated voltage UN
3~400/690 V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-20 bis -10000 °C
Number of wings

Protection class
IP54
Motor protection

Fan series match code
RG35TItem number
ZV-112221
Motor technology
AC
Rated voltage UN
3~400V V
Rated frequency fN
50 Hz
Thermal class
Wärmeklasse F
Permissible flow medium temperature
-20 bis 80 °C
Number of wings

Protection class
IP55
Motor protection
Standard housing position G90°
Fan series match code
RG35TItem number
ZV-112222
Motor technology
AC
Rated voltage UN
3~400V V
Rated frequency fN
50 Hz
Thermal class
Wärmeklasse F
Permissible flow medium temperature
-20 bis 80 °C
Number of wings

Protection class
IP55
Motor protection
Standard housing position G90°
Fan series match code
RG35TItem number
ZV-112223
Motor technology
AC
Rated voltage UN
3~400V V
Rated frequency fN
50 Hz
Thermal class
Wärmeklasse F
Permissible flow medium temperature
-20 bis 80 °C
Number of wings

Protection class
IP55
Motor protection
Standard housing position G90°
Fan series match code
RG40TItem number
ZV-112224
Motor technology
AC
Rated voltage UN
3~400V V
Rated frequency fN
50 Hz
Thermal class
Wärmeklasse F
Permissible flow medium temperature
-20 bis 80 °C
Number of wings

Protection class
IP55
Motor protection
Standard housing position G90°
Fan series match code
RG40TItem number
ZV-112225
Motor technology
AC
Rated voltage UN
3~400V V
Rated frequency fN
50 Hz
Thermal class
Wärmeklasse F
Permissible flow medium temperature
-20 bis 80 °C
Number of wings

Protection class
IP55
Motor protection
Standard housing position G90°
Fan series match code
RG40TItem number
ZV-112226
Motor technology
AC
Rated voltage UN
3~400V V
Rated frequency fN
50 Hz
Thermal class
Wärmeklasse F
Permissible flow medium temperature
-20 bis 80 °C
Number of wings

Protection class
IP55
Motor protection
Standard housing position G90°
Fan series match code
RG45TItem number
ZV-112227
Motor technology
AC
Rated voltage UN
3~400V V
Rated frequency fN
50 Hz
Thermal class
Wärmeklasse F
Permissible flow medium temperature
-20 bis 80 °C
Number of wings

Protection class
IP55
Motor protection
Standard housing position G90°
Fan series match code
RG45TItem number
ZV-112228
Motor technology
AC
Rated voltage UN
3~400V V
Rated frequency fN
50 Hz
Thermal class
Wärmeklasse F
Permissible flow medium temperature
-20 bis 80 °C
Number of wings

Protection class
IP55
Motor protection
Standard housing position G90°
Fan series match code
RG45TItem number
ZV-112229
Motor technology
AC
Rated voltage UN
3~400V V
Rated frequency fN
50 Hz
Thermal class
Wärmeklasse F
Permissible flow medium temperature
-20 bis 80 °C
Number of wings

Protection class
IP55
Motor protection
Standard housing position G90°
Fan series match code
RG50TItem number
ZV-112230
Motor technology
AC
Rated voltage UN
3~400V V
Rated frequency fN
50 Hz
Thermal class
Wärmeklasse F
Permissible flow medium temperature
-20 bis 80 °C
Number of wings

Protection class
IP55
Motor protection
Standard housing position G90°
Fan series match code
RG50TItem number
ZV-112231
Motor technology
AC
Rated voltage UN
3~400V V
Rated frequency fN
50 Hz
Thermal class
Wärmeklasse F
Permissible flow medium temperature
-20 bis 80 °C
Number of wings

Protection class
IP55
Motor protection
Standard housing position G90°
Fan series match code
RG50TItem number
ZV-112232
Motor technology
AC
Rated voltage UN
3~400V V
Rated frequency fN
50 Hz
Thermal class
Wärmeklasse F
Permissible flow medium temperature
-20 bis 80 °C
Number of wings

Protection class
IP55
Motor protection
Standard housing position G90°
Fan series match code
RG56TItem number
ZV-112233
Motor technology
AC
Rated voltage UN
3~400V V
Rated frequency fN
50 Hz
Thermal class
Wärmeklasse F
Permissible flow medium temperature
-20 bis 80 °C
Number of wings

Protection class
IP55
Motor protection
Standard housing position G90°
Fan series match code
RG56TItem number
ZV-112234
Motor technology
AC
Rated voltage UN
3~400V V
Rated frequency fN
50 Hz
Thermal class
Wärmeklasse F
Permissible flow medium temperature
-20 bis 80 °C
Number of wings

Protection class
IP55
Motor protection
Standard housing position G90°
Fan series match code
RG56TItem number
ZV-112235
Motor technology
AC
Rated voltage UN
3~400V V
Rated frequency fN
50 Hz
Thermal class
Wärmeklasse F
Permissible flow medium temperature
-20 bis 80 °C
Number of wings

Protection class
IP55
Motor protection
Standard housing position G90°
Fan series match code
RG63TItem number
ZV-112236
Motor technology
AC
Rated voltage UN
3~400V V
Rated frequency fN
50 Hz
Thermal class
Wärmeklasse F
Permissible flow medium temperature
-20 bis 80 °C
Number of wings

Protection class
IP55
Motor protection
Standard housing position G90°
Fan series match code
RG63TItem number
ZV-112237
Motor technology
AC
Rated voltage UN
3~400V V
Rated frequency fN
50 Hz
Thermal class
Wärmeklasse F
Permissible flow medium temperature
-20 bis 80 °C
Number of wings

Protection class
IP55
Motor protection
Standard housing position G90°
Fan series match code
RG63TItem number
ZV-112238
Motor technology
AC
Rated voltage UN
3~400V V
Rated frequency fN
50 Hz
Thermal class
Wärmeklasse F
Permissible flow medium temperature
-20 bis 80 °C
Number of wings

Protection class
IP55
Motor protection
Standard housing position G90°
Fan series match code
ZF063-___.__.V5Item number
ZV-169858
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 65 °C
Number of wings
5
Protection class
IP54
Motor protection
Wall ring plate, made from plastic, without protective grate
Fan series match code
ZF063-___.__.V5Item number
ZV-169858
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 50 °C
Number of wings
5
Protection class
IP54
Motor protection
Wall ring plate, made from plastic, without protective grate
Fan series match code
ZF063-___.__.V5Item number

Motor technology
AC
Rated voltage UN
3~230/400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
5
Protection class
IP54
Motor protection

Fan series match code
ZF063-___.__.V5Item number

Motor technology
AC
Rated voltage UN
3~230/400 +/-10% V
Rated frequency fN
60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 40 °C
Number of wings
5
Protection class
IP54
Motor protection

Fan series match code
ZF063-___.__.V5Item number
ZV-185884
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-35 bis 50 °C
Number of wings
5
Protection class
IP54
Motor protection
Wall ring plate, made from plastic, without protective grate
Fan series match code
ZF071-___.__.V3Item number

Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 65 °C
Number of wings
3
Protection class
IP54
Motor protection

Fan series match code
ZF071-___.__.V3Item number

Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 50 °C
Number of wings
3
Protection class
IP54
Motor protection

Fan series match code
ZF071-___.__.V3Item number

Motor technology
AC
Rated voltage UN
3~230/400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
3
Protection class
IP54
Motor protection

Fan series match code
ZF071-___.__.V3Item number

Motor technology
AC
Rated voltage UN
3~230/400 +/-10% V
Rated frequency fN
60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 70 °C
Number of wings
3
Protection class
IP54
Motor protection

Fan series match code
ZF071-___.__.V3Item number

Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 50 °C
Number of wings
3
Protection class
IP54
Motor protection
Wall ring plate, made from plastic, without protective grate
Fan series match code
ZF091-___.__.V3Item number
ZV-180102
Motor technology
AC
Rated voltage UN
1~230 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 45 °C
Number of wings
3
Protection class
IP54
Motor protection
Wall ring plate, non-lacquered, with protective grate
Fan series match code
ZF091-___.__.V3Item number
ZV-169697
Motor technology
AC
Rated voltage UN
3~230/400 +/-10% V
Rated frequency fN
50 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 70 °C
Number of wings
3
Protection class
IP54
Motor protection
Wall ring plate, non-lacquered
Fan series match code
ZF091-___.__.V3Item number
ZV-169697
Motor technology
AC
Rated voltage UN
3~230/400 +/-10% V
Rated frequency fN
60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 45 °C
Number of wings
3
Protection class
IP54
Motor protection
Wall ring plate, non-lacquered
Fan series match code
ZF091-___.__.V3Item number
ZV-185888
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-35 bis 40 °C
Number of wings
3
Protection class
IP54
Motor protection
Wall ring plate, made from plastic, without protective grate
Fan series match code
ZN045-6I_.BD.V7P3Item number
ZV-174304
Motor technology
EC
Rated voltage UN
1~200-277V V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-35 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
L
Fan series match code
ZN050-__L.4_.V7P1Item number
ZV-161772
Motor technology
AC
Rated voltage UN
1~230V +/-10% V
Rated frequency fN
50/61 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
L
Fan series match code
ZN050-__L.4_.V7P1Item number
ZV-161788
Motor technology
AC
Rated voltage UN
1~230V +/-10% V
Rated frequency fN
50/62 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
L
Fan series match code
ZN063-VD_.6N.V7P6Item number
ZV-169028
Motor technology
AC
Rated voltage UN
3~400 +/-10% / 3~460 +/-10% V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-40 bis 70 °C
Number of wings
7
Protection class
IP54
Motor protection
L
Fan series match code
ZN071-ZI_.DG.V7P3Item number
ZV-182547
Motor technology
EC
Rated voltage UN
1~200-277V V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
10000 bis 60 °C
Number of wings
7
Protection class
IP54
Motor protection
L
Fan series match code
ZN071-ZI_.DG.V7P3Item number
ZV-182547
Motor technology
EC
Rated voltage UN
1~200-277 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-25 bis 60 °C
Number of wings
7
Protection class
IP55
Motor protection
L
Fan series match code
ZN091-ZI_.GL.V5Item number
ZV-184551
Motor technology
EC
Rated voltage UN
3~380-480 V
Rated frequency fN
50/60 Hz
Thermal class
THCL 155
Permissible flow medium temperature
-35 bis 40 °C
Number of wings
5
Protection class
IP55 plus
Motor protection
Q

Ventilation technology

Consulting and service

Do you have any questions about our products or want a quote? Just give us a call or write us an email. We would be glad to assist you!

We use system-related session cookies to ensure the function of this site and to simplify use. Furthermore, cookies are set by Google Analytics to help us optimise the content of the pages.
Accept everything
Only technically necessary cookies
Further information
arrow_upward
