MatchcodeQG10A-2DM.68.FKItem number ZV-112113 |  |
|---|---|
| Product group | Cross-flow fan |
| Model | Standard |
| Design | Cross-flow fan module with housing and three-phase motor |
| Name | |
| Blade series | QG |
| Fan series match code | QG10A-2DM._ |
| Blade diameter [cm] | 10 |
| Motor technology | AC |
| Rated voltage UN [V] UN [V] | 3~230/400 +/-10% |
| Rated frequency fN [Hz] | 50 |
| Input power P1 [kW] | 0,56 |
| Rated current IN [A] | 0,56 |
| Rated speed nN [min-1] | 2,05/1,18 |
| Current rating increase Δ I [%] | 2800 |
| Controlling starting current IA [A] | |
| Operating capacitor C400V [µF] | |
| Thermal class | THCL 155 |
| Minimum permissible flow medium temperature [°C] | |
| Maximum permissible flow medium temperature [°C] | |
| Electrical connection | Extended connection cable, 155 cm |
| Sound pressure level LpA or LwA [dB(A)] | |
| Number of wings | |
| Rotor | |
| Wall ring plate | |
| Conformity | ErP 2015 |
| Weight [kg] | 10.8 |
| Airflow direction | |
| Model | |
| Max. volume flow qv, (where psf = 0 Pa) [m³/h] | |
| Max. pressure psf [Pa] | |
| Max. volume flow qv [m³/h] (at max. psf [Pa]) |
